●QC system
Acceptance inspection
We provide for reliable products thorough inspection system on process to build from arrival to shipment by experienced and specialized inspectors.
We will inspect products, purchased from other companies, as inspection outsourcing.
We provide for reliable products thorough inspection system on process to build from arrival to shipment by experienced and specialized inspectors.
We will inspect products, purchased from other companies, as inspection outsourcing.
| inspection item | inspection content | inspection equipment |
|---|---|---|
| visual inspection |
packaging condition actual product comparison quantity check check the appearance configuration (scratche, discoloration, crack, stain) marking specification, state, checking lead terminal (nebtness, discoloration, boll collapse etc.) check the environment-related product, Pb-Free, RoHS etc. |
Optical microscope Zoom type stereo microscope Microscope Visual inspection machine |
| X-ray inspection (non-destructive testing) |
check the structure in case IC, LSI shape of leadframe, die size, condtion of bonding wire compare check both official product and customer-supplied product |
Micro focus X-ray inspection system |
| X-ray fluorescence analyzer |
Pb containt analysis RoHS 6 materials 5 elements composition analysis other element analysis thin film FP |
X-ray fluorescence analyzer equipment |
|
element analysis （Laser-Induced Breakdown Spectroscopy, LIBS） |
foreign material analysis: detrmine constituent elements of sample surface (plating etc) multi-layer analysis: detrmine hierarchical constituent elements of sample multipoint analysis: detrmine constituent elements of sampe surface plurally of places at the same time |
laser element analaysis equipment |
| electrical characteristics |
V-I characteristics characteristics of transistor, diode open, short |
curve tracer |
| others |
blanck check of microcomputer, PLD, memory wettability of solder check packege decapsulation of IC, LSI |
We will handle it through our group companies or partner companies (depends on the request, it will be charged services) |
※The above inspection also includes the option of issuing an inspection report if necessary.
※X-ray inspection, X-ray fluorescence analyzer, element analysis, electrical characteristics will be conducted if necessary, and may be charged depending on the request.
Inspection equipment
- ●Model number :
- DSZT-70IFL
- ●Manufacturer :
- Carton Optical Industries, Ltd.
- ●Model number :
- LW-830T
- ●Manufacturer :
- Wraymer Co.,Ltd.
- ●Model number :
- VHX-8000
- ●Manufacturer :
- KEYENCE CORPORATION
- ●Model number :
- LI700E
- ●Manufacturer :
- Yasunaga Co.,Ltd.
- ●Model number :
- SMX-1000L Plus
- ●Manufacturer :
- Shimadzu Corporation
- ●Model number :
- EA1400
- ●Manufacturer :
- Hitachi High-Tech Corporation
- ●Model number :
- VHX-8000＋EA-300
- ●Manufacturer :
- KEYENCE CORPORATION
- ●Model number :
- CS-3200
- ●Manufacturer :
- Iwasaki Electric Co.,Ltd
- ●Model number :
- BeeProg2
- ●Manufacturer :
- Elnec Japan
- ●Model number :
- PR36-3A
- ●Manufacturer :
- TEXIO TECHNOLOGY CORPORATION
- ●Model number :
- CUXⅡ-600A
- ●Manufacturer :
- Shinko Denshi Co., Ltd.
- ●Model number :
- DT4281
- ●Manufacturer :
- HIOKI E.E. CORPORATION
